Advanced wet grinding and emulsification for precise process requirements

FrymaKoruma's technology solutions are used to produce various types of products: Active pharmaceutical ingredients, lipstick masses, creams or even mayonnaise, ketchup and chocolate are produced on the lines. Whether wet grinding, emulsifying, dispersion, blending, deaeration or deagglomeration – FrymaKoruma provides the appropriate process for the production of high-quality products with short production times.

Teamwork

For me, mechanical engineering is like a gear train. It doesn't work without the gears. Our products never come from one person. They are the product of a team. I am always happy to be a part of this ProXES team.
Tobias Meyer, Teamleiter Montage Prozessanlagen, Rheinfelden

Our systems for precise wet grinding, emulsification and dispersion

  • ProxxDHigh-class emulsifier

    The PROXXD is ProXES's premium emulsifier for the most demanding food and industrial emulsification applications, delivering exceptional product quality and process reliability at high throughput.

    Key features: Premium performance, high throughput, robust construction, flexible process control

    • Production capacity for
      full fat mayonnaise: up to 6,000 kg/h*
    • Production capacity for
      low fat mayonnaise (30% oil): up to 4,000 kg/h*
    • Oil dosing: up to 3.0 kg/s
    • Specific energy input: on average 5 kWh/ton
    • Batch volume: 500 l
    • Dimensions – basic concept: L 230 x H 280 x W 210 cm
    • Weight: approx. 2,000 kg

    *Based on FrymaKoruma standard recipies and dependent on system configuration.

    Download our latest brochure to find out more about our products.

    Download

  • DinexPersonal Care & Pharma high shear emulsifier

    The DINEX is a high shear emulsifier engineered for the production of personal care and pharmaceutical products such as creams, lotions, and ointments. It ensures precise droplet size control under GMP-compliant conditions.

    Key features: High shear rotor-stator, GMP-compliant design, CIP/SIP capable, batch processing

    Capacities up to 3,000 kg/hour*

    • Functions:
      • homogenizing
      • mixing
      • dispersing
      • deaeration
      • cooling
      • heating
      • cleaning
      • sterilization
    • Main applications:
      • cosmetics
      • sterile pharmaceuticals
      • cream
      • ointment
      • gels
      • toothpaste

    *Application cold processed emulsion standard FrymaKoruma formulation

  • VMEUniversal mixing and dispersing
    • Capacities up to 1,700 kg/hour*
    • From lab to industrial scale
    • Functions:
      • homogenizing
      • mixing
      • dispersing
      • heating
      • cooling
      • deaeration
      • deagglomeration
    • Main applications:
      • toothpaste
      • creams
      • sealants
      • lotions and pastes

    *Application toothpaste standard FrymaKoruma formulation



  • Vacuum Deaerator Continuous automatic removal of air
    • Capacities up to 30.000 kg/hour*
    • From lab to industrial scale
    • Functions:
      • vacuum deaeration
    • Main applications:
      • mustard
      • paper coatings
      • honey
      • liquid detergents
      • carbomer suspensions
      • lubrication grease

    *Application: low viscous products

  • DILInline emulsifier

    The DIL inline emulsifier integrates directly into continuous production lines, enabling uninterrupted emulsification with minimal footprint. Ideal for high-volume food and cosmetics manufacturing.

    Key features: Continuous inline processing, high throughput, compact design, easy integration

    • Capacities up to 60.000 l/hour*
    • From lab to industrial scale
    • Functions:
      • homogenizing
      • emulsifying
      • suspending
    • Main applications:
      • sauces & dressings
      • creams & ointments
      • emulsions & suspensions
      • agro chemicals

    *Application: low viscous products

  • POW-DILVersatile powder liquid mixing
    • Induction rate up to 1.0 kg/s
    • From pilot to industrial scale
    • Functions:
      • powder induction
      • powder wetting
      • homogenizing
      • emulsifying
      • suspending
    • Main applications:
      • Thickeners
      • Starch
      • Pigments
      • Sugar solution
  • Perforated Disc Mill powerful grinding and pre-grinding
    • Capacities up to 40,000 kg/h* (Inline)​
    • Capacities up to 10,000 kg/h** (Stand- alone)
    • From lab to industrial scale
    • Functions:
      • pre-grinding
      • pulping
      • mashing
    • Main applications:
      • fruit and vegetable
      • soya beans slurry
      • meat and fish pastes
      • pet food
      • chemical suspensions
      • paper coatings
      • polymers

    *Application:  low viscous products / **Application: whole vegetables; coarse paste



  • MDMulti-zone pre-grinding
    • Capacities up to 20,000 kg/hour* (inline)
    • From pilot to industrial scale
    • Functions:
      • wet coarse grinding
      • dispersing
    • Main applications:
      • plant-based drinks made of
        • Legumes
        • Grains
        • Nuts
        • Seeds

    *Application: low viscous products

  • Toothed Colloid Mill variable wet milling

    The Toothed Colloid Mill provides variable wet milling for demanding applications requiring extremely fine particle size reduction, such as mustard, spice pastes, and pharmaceutical suspensions.

    Key features: Adjustable gap, extremely fine particle reduction, suitable for high-viscosity products

    • Capacities up to 40,000 kg/h* (Inline)​
    • Capacities up to 5,000 kg/h** (Stand- alone)
    • From lab to industrial scale
    • Functions:
      • wet fine grinding
      • dispersing
      • emulsifying
    • Main applications:
      • soy, rice, oat slurry
      • nuts & seeds pastes
      • tablet coatings
      • decorative cosmetics
      • creams & ointments
      • chemical suspensions
      • lubrication grease

    *Application: low viscous products / **Application: Nuts & Seeds; coarse paste



  • Corundum Stone Millversatile wet milling and dispersing
    • Capacities up to 5,000 kg/h* (Inline)
    • Capacities up to 3,000 kg/h (Stand- alone)
    • From lab to industrial scale
    • Functions:
      • wet fine grinding
      • dispersing
    • Main applications:
      • mustard
      • tahina
      • nut & seed pastes
      • cocoa nibs
      • softgel fillings
      • Pigments slurries
      • agro chemicals

    *Application: low viscous products / **Application: Nuts & Seeds; coarse paste

    Download our latest brochure to find out more about our products.

    Download

  • Inline MelterContinuous melting on demand
    • Capacities up to 1500 kg/hour* (inline)
    • From pilot to industrial scale
    • Functions:
      • continuous melting on demand
    • Main applications:
      • chocolate drops
      • chocolate rework
      • wax pellets

    *Application: dark chocolate

  • Co-BallHigh-performance very fine grinding
    • Capacities up to 1.000 kg/hour* (Inline setup)
    • Fineness down to <1μm
    • From lab to industrial scale
    • Functions:
      • ultra fine grinding
    • Main applications:
      • paints and varnishes
      • softgel fillings
      • lipstick masses
      • chocolate fillings and creams
      • API suspension

    *Application cocoa liquer
